Button-ups, ties and socks built on arches, trusses and the 28-day break.

This week in Civil Engineering,

A century-old island in San Francisco Bay sinks as the sea rises, a cement composite casts its own self-powered sensors, an AI co-pilot speeds structural design, and physics sharpens typhoon surge forecasts.

Get it by email

Download MP3

Behind this page you follow one load to the ground. The rear axle of an AASHTO HL-93 design truck, 32 kip, stands on the deck of a reference suspension bridge (a model: 1,000 m main span, cable sag a tenth of the span, six lanes). Its load climbs the hanger above it, a pull, and runs up the main cable, a parabola under a load spread along the span, to the saddle on the tower, where the cable’s tension is 144.2 MN. There it turns down the concrete tower, a push, into the pier in the river and the caisson below it, and the caisson presses on the rock at 0.76 MPa. Below the base the pressure spreads out as Boussinesq’s pressure bulb, falling to a tenth 2.09 caisson widths down. The deck sits 54.0 m above the design flood, and the flood scours a hole 11.6 m deep around the pier (HEC-18). Members that pull are red, members that push blue, the bending deck gray, and the axle’s path amber. Loads: dead load plus HL-93, unfactored.

Welcome in

For anyone who has hunted zero-force members

You know the site-office kettle, the hi-vis that never quite dries, and the smell of fresh concrete on a cold morning. You know the wait for the 28-day breaks, and the driver who swears the load is fine while you stand there holding a tamping rod. You remember the first structure you could read: a truss on an exam paper, its pushes and pulls sorting themselves joint by joint, the members that carry nothing turning up exactly where they should. You were an engineer from then on.

Start with everything

THE BUILT ENVIRONMENT, Bone
THE BUILT ENVIRONMENTRegular price $65 Sale price $58.50Shop now

Colorway
Bone

Whole-field medallions · repeats every 18 in

Short-sleeve button-up · XS–4XL

THE BUILT ENVIRONMENT

The whole field, on one shirt.

Civil Engineering brought together in one design, printed edge to edge: 25 medallions from the field’s designs, with the equations from across the subject. Related images are spread across the pattern so no two neighbors repeat.

  • Print scaleThe pattern repeats every 18 inches, with seamless edges.
  • StylesPhotoreal on bone, engraving or blueprint.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

COMMON GROUND

A topographic portrait of the field.

Recognizable forms from Civil Engineering rise as contour landscapes. Lines follow the outlines and continue across the ground between them, with names fitted along the contours.

  • Print scaleThe pattern repeats every 18 inches, with seamless edges.
  • The paletteTwo colorways, shown at the same print scale.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Socks mix and match across every field: three pairs for $69, and two ship free in the U.S.

Crew socks · One size

Crew socks

A field of your own, from cuff to toe.

  • The pattern
  • The previewA studio mockup; photos of the finished pair are on the way.
Shop now · Regular price $26 Sale price $23.40

Leave your email and we’ll write the day this pair is ready.

Necktie · 3.5 in wide

Subject ties

A formal introduction to your field.

  • The color
  • The previewStudio render of the tie. Zoom shows the print up close.
Shop now · Regular price $36 Sale price $32.40

Leave your email and we’ll write the day this tie is ready.

More designs to explore

Short-sleeve button-up · XS–4XL

LOAD PATH

Push, pull, hang, triangulate: every load finds its way to the ground.

A masonry arch carries its own weight in pure compression, and it stands as long as a line of thrust can be drawn inside its stones. Robert Hooke saw the principle in 1675: a hanging chain, turned upside down, is the shape of an arch. A search over every admissible thrust shows that a semicircular Roman arch needs a ring only 0.1075 of its radius deep, with the haunch hinges 54.5° from the crown, the figures Milankovitch gave in 1907. Gaudí scaled Hooke’s rule up to a whole church. For about ten years from 1898 he refined a model hanging upside down in his workshop, strings for arches and columns and sachets of lead shot for loads, then photographed it and painted over the inverted prints.

Hang a level deck from a chain and the load is spread along the span instead of along the chain, so the curve becomes a parabola. Every suspension cable is designed as one, though at a sag of a tenth of the span it differs from a catenary by only 32 cm in a kilometer. Trusses sort their members into pulls and pushes. Thomas and Caleb Pratt patented theirs in 1844, and loaded at its inner joints every diagonal is in tension, which suited iron, while the center post carries nothing at all. And a column pushed too hard steps sideways. Euler found the load in 1744; how the ends are held sets the effective length, from twice the column for a flagpole to half for one clamped at both ends.

  • The Voussoir ArchA dry-jointed Roman arch of seventeen travertine voussoirs, every joint aimed at one center, the ring nearly twice as deep as it needs to be.
  • Gaudí’s Hanging ModelGaudí’s model rebuilt: pale strings and canvas sachets hanging from a board, straight between sachets, the nave arch deepest.
  • Euler Buckling and Effective LengthFour identical steel columns under 1, 4, 8 and 16 brass disks, each bowed in its own mode by the load that buckles it.
  • Parabola, Not CatenaryA brass chain carrying a level glass deck on fifteen vertical threads, shortest in the middle, leaving each post at 45°.
  • Warren and Pratt TrussesPratt above, Warren below, every member painted by its force: red pulling, blue pushing, gray carrying nothing at all.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

MAIN SPAN

Every long span is a lesson; some of them were expensive.

After the Tay Bridge fell in a gale in 1879, the crossing of the Firth of Forth had to look as safe as it was. John Fowler and Benjamin Baker chose the balanced cantilever: arms of 680 feet and suspended spans of 350 make two main spans of 1,710 feet, the longest in the world when the bridge opened in 1890. To explain it Baker had a photograph taken in 1887: two men on chairs, arms out in tension and sticks in compression, carrying the engineer Kaichi Watanabe between them as the suspended span, with bricks for anchorage. At Brooklyn, John A. Roebling died before work began, and his son Washington directed it, crippled by caisson disease, with Emily Warren Roebling carrying his instructions to the site.

Its four main cables were spun in the air between 1877 and 1878, wire by wire, into 19 strands each, and when a contractor was caught supplying rejected wire, Roebling added extra wires rather than tear any out. The first modern cable-stayed bridge, Sweden’s Strömsund, came in 1955, and designers have argued fan against harp ever since. Tacoma Narrows opened in July 1940 with a deck 1/72 of its span wide and fell that November, twisting in a wind of about 42 mph: not resonance but flutter, energy drawn from a steady wind. And floods and scour bring down more bridges than traffic ever has; the Schoharie Creek bridge in New York fell in 1987 after scour under a pier.

  • Brooklyn Bridge Cable SpinningThe cut end of a spun main cable: thousands of bright parallel wire ends in 19 hexagonal strands, 1, 6 and 12, wrapped around.
  • Cable-Stayed: Fan and HarpTwo single-pylon models, twelve stays each: above, a fan meeting at the pylon head; below, a harp of parallel stays.
  • Bridge ScourA flume through glass: a half-pier against the wall, a scour hole about two pier widths deep at its nose, a sand mound behind.
  • Tacoma Narrows, 1940The 1940 deck mid-twist, lamp standards leaning with it: one way over the near half, the other over the far half, level at midspan.
  • The Forth Bridge CantileverBaker’s 1887 human cantilever in bronze, cast as faceless lay figures: arms pulling and sticks pushing, a third figure on the plank between, bricks at each end.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

28 DAYS

Tested at 28 days, trusted for nineteen centuries.

Concrete is judged twice: fresh, by how it flows, and hard, by how it breaks. The slump test takes a steel cone 300 mm tall, fills it in three layers rodded 25 times each, and lifts it away; the drop of the concrete’s top is the slump, and its shape matters as much as the number. It is crude, empirical and about a century old, and it survives because it takes two minutes on a site with no power. Four weeks later a cylinder from the same truck is crushed. Its height is twice its diameter so that friction at the platens does not dominate, which is also why a good break leaves two cones pointing at each other.

Duff Abrams showed in 1918 that strength falls exponentially with the ratio of water to cement, and the cylinder is how that law is policed. Steel carries the tension concrete cannot. In a column built for earthquakes, closed hoops with 135° hooks bent back into the core hold the bars once the cover spalls; at Olive View Hospital in 1971, spirally reinforced columns survived where tied ones crumbled. Freyssinet patented prestressing in 1928, and T. Y. Lin’s load balancing of 1963 drapes a tendon so that the lift it gives cancels the beam’s own weight. And the Pantheon, finished around AD 125, has no steel at all: 43.3 m across and 43.3 m high, it would hold a sphere exactly.

  • The Cylinder BreakA crushed 150 by 300 mm cylinder in its steel caps: two cones pointing at each other, the shell split away in slabs.
  • The Pantheon DomeLooking straight up from the center of the floor: five rings of 28 stepped coffers closing in on a disk of sky.
  • The Slump TestThe upturned cone beside a true slump of fresh concrete, the tamping rod laid across both to show the 75 mm drop.
  • Confinement and the Seismic HookA column cage of eight bars, every hoop closed with 135° hooks into the core, hoops crowding together at both ends.
  • Post-Tensioning and Load BalancingA glass-fronted post-tensioned beam: one tendon draped in a smooth parabola from mid-depth at each anchor to near the bottom at midspan.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

FREEBOARD

Water always wins; these are the terms we negotiate.

Freeboard is the height a designer keeps between the water and the top of the wall. A morning-glory spillway drains a full reservoir through a funnel in the lake itself, a weir bent into a circle whose capacity grows with the head to the power 3/2. Its crest follows the underside of a free-falling sheet, so the water clings without pulling a vacuum, and vanes are added where needed to stop a choking vortex. Beneath the cities, the Victorians built their sewers like eggs standing on end. After the Great Stink of 1858, Joseph Bazalgette built many of London’s intercepting sewers to that shape: one and a half times as tall as wide, with a tight invert that keeps a dry-weather trickle deep and fast.

Ralph Parshall built his flume at the Colorado Agricultural College in the 1920s: walls that converge, a short throat whose floor drops steeply, then walls that diverge, so the flow passes critical depth and a single depth reading gives the discharge. Wastewater operators still read them every shift. When fast, shallow water meets slow, deep water it jumps. Bidone described the jump in 1820, and Bélanger’s momentum law says that at a Froude number of 5 the depth rises 6.59 times and 49% of the energy is lost, which is why spillways end in stilling basins. And the miter gate, usually credited to Leonardo in Milan in the 1490s, lets the water itself hold a lock shut.

  • The Morning-Glory SpillwayA round concrete lip in dark, still water, a glassy sheet pouring evenly over the whole rim into the shaft, with no swirl.
  • The Egg-Shaped SewerThe end of a Victorian brick sewer, an egg on its narrow end, 1½ times as tall as wide, a trickle in the invert.
  • The Parshall FlumeA Parshall flume in pale concrete: walls converging, a steep throat, a standing wave beyond, the stilling well two-thirds along.
  • The Hydraulic JumpA thin, fast sheet leaving a sluice gate, then a jump through a white roller into water 6.6 times as deep.
  • The Miter GateA canal lock from downstream: two pairs of oak miter gates, each a shallow V pointing upstream, three water levels stepping down.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

REFUSAL

Everything rests on the ground, and the ground gets a vote.

The ground under a structure is the one material its engineer cannot choose, so geotechnical engineers learn its opinions in the laboratory. Albert Atterberg defined in 1911 the water contents at which a clay turns from brittle to plastic to liquid, and Arthur Casagrande made the liquid limit a machine: the water content at which 25 blows of a brass cup, dropped 10 mm twice a second, close a groove along 13 mm. Coulomb proposed in 1773 that soil fails when shear on a plane reaches cohesion plus friction, and Mohr’s circle later showed which plane goes first. In the triaxial cell a sand with a 30° friction angle fails at three times the cell pressure, along a plane 60° from the horizontal.

Boussinesq solved the stress under a point load in 1885, and summed under a footing it gives the pressure bulbs of every foundation textbook: under a square footing the stress falls to a tenth of the footing pressure about two widths down, the rule of thumb for how deep a site investigation must reach. Water gets a vote too. Flow under a sheet-pile wall obeys Laplace’s equation, and a flow net of curvilinear squares gives the leakage by counting channels and drops; where the water rises into the dig, a gradient near 1 makes the floor boil. And Pisa’s bell tower began leaning while it was being built, on soft clay. Between 1999 and 2001 soil drawn from beneath its high side eased it back about half a degree.

  • Mohr–Coulomb and the Triaxial TestA triaxial cell after failure: a soil cylinder in its rubber membrane, sheared along one flat plane at 60° to the horizontal.
  • The Leaning Tower of PisaA white marble model of eight stories, leaning about 4°, its upper stories built a little less tilted, so it faintly curves.
  • The Pressure BulbSix glowing bulbs laser-engraved in crystal under a steel footing: stress at 90% of the footing pressure down to 10%, two widths deep.
  • The Liquid LimitThe Casagrande cup on its rubber base, a grooved clay pat closed along a short middle stretch after 25 blows.
  • Seepage into a CofferdamA glass-fronted cofferdam in section: gold flow lines under the piles, blue head lines across them, four channels and ten drops a side.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

EQUATION STRIPE

From the Euler–Bernoulli beam to the average end area, every line labeled.

Civil engineering spans structures, soils, water, roads and survey, and every part of it leaves a few equations behind. The Equation Stripe sets forty-five of them in rows, each introduced by its name in capitals, so MOMENT DISTRIBUTION, BEARING CAPACITY and MANNING’S EQUATION read at a glance. Together they make a working civil engineer’s toolkit: how beams and frames carry load and how codes factor it, how soil settles, seeps and slides, how water flows in pipes, channels and aquifers, how roads are shaped for the traffic on them, and how the ground is surveyed and moved.

Six carry the science of the picture designs: MOHR–COULOMB, BOUSSINESQ STRESS, FLOW NET SEEPAGE and TERZAGHI CONSOLIDATION under REFUSAL, and MANNING’S EQUATION and HYDRAULIC JUMP under FREEBOARD. The rest read like a professional exam in miniature: the three-moment equation, slope-deflection and Hardy Cross’s moment distribution, the Whitney stress block, LRFD load combinations, Rankine earth pressure, Darcy’s law, Hazen–Williams, the rational method and the SCS curve number, Greenshields’ traffic model and the fourth-power law of pavement damage.

  • Euler–Bernoulli BeamEI d4w/dx4 = q(x)
  • Simple-Span BeamMmax = wL2/8, δmax = 5wL4/(384EI)
  • Three-Moment EquationMAL1 + 2MB(L1 + L2) + MCL2 = −(w1L13 + w2L23)/4
  • Slope-DeflectionMAB = (2EI/L)(2θA + θB − 3ψ) + FEMAB
  • Unit-Load Method1·Δ = ∫mM/(EI) dx
  • Moment DistributionDFi = Ki/∑K, K = 4EI/L, COF = 1/2
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

EULER–BERNOULLI BEAMEI d4w/dx4 = q(x)·SIMPLE-SPAN BEAMMmax = wL2/8, δmax = 5wL4/(384EI)·THREE-MOMENT EQUATIONMAL1 + 2MB(L1 + L2) + MCL2 = −(w1L13 + w2L23)/4·SLOPE-DEFLECTIONMAB = (2EI/L)(2θA + θB − 3ψ) + FEMAB·UNIT-LOAD METHOD1·Δ = ∫mM/(EI) dx·MOMENT DISTRIBUTIONDFi = Ki/∑K, K = 4EI/L, COF = 1/2·SECANT FORMULAσmax = (P/A)[1 + (ec/r2)sec((Le/(2r))√(P/(EA)))]·PLASTIC MOMENTMp = FyZ, Z/S = 1.5 (rectangle)·LRFD DESIGNφRn ≥ ∑iγiQi·LOAD COMBINATIONU = 1.2D + 1.6L + 0.5(Lr or S or R)·WHITNEY STRESS BLOCKa = Asfy/(0.85f'cb), Mn = Asfy(d − a/2)·SEISMIC BASE SHEARV = CsW, Cs = SDS/(R/Ie)·EFFECTIVE STRESSσ' = σ − u·MOHR–COULOMBτf = c' + σ' tan φ'·BEARING CAPACITYqu = c'Nc + qNq + 0.5γBNγ·RANKINE EARTH PRESSUREKa = tan2(45° − φ'/2), Kp = tan2(45° + φ'/2)·PRIMARY CONSOLIDATIONSc = (CcH/(1 + e0))log10((σ'0 + Δσ')/σ'0)·TERZAGHI CONSOLIDATION∂u/∂t = cv∂2u/∂z2, Tv = cvt/Hdr2·DARCY’S LAWv = ki, Q = kiA·FLOW NET SEEPAGEq = kHNf/Nd·PHASE RELATIONSSe = wGs, e = n/(1 − n)·INFINITE SLOPEFS = tan φ'/tan β (c' = 0, dry)·BOUSSINESQ STRESSΔσz = 3Pz3/(2πR5), R2 = r2 + z2·MANNING’S EQUATIONV = (1/n)Rh2/3S1/2 (SI)·EULER–BERNOULLI BEAMEI d4w/dx4 = q(x)·SIMPLE-SPAN BEAMMmax = wL2/8, δmax = 5wL4/(384EI)·THREE-MOMENT EQUATIONMAL1 + 2MB(L1 + L2) + MCL2 = −(w1L13 + w2L23)/4·SLOPE-DEFLECTIONMAB = (2EI/L)(2θA + θB − 3ψ) + FEMAB·UNIT-LOAD METHOD1·Δ = ∫mM/(EI) dx·MOMENT DISTRIBUTIONDFi = Ki/∑K, K = 4EI/L, COF = 1/2·SECANT FORMULAσmax = (P/A)[1 + (ec/r2)sec((Le/(2r))√(P/(EA)))]·PLASTIC MOMENTMp = FyZ, Z/S = 1.5 (rectangle)·LRFD DESIGNφRn ≥ ∑iγiQi·LOAD COMBINATIONU = 1.2D + 1.6L + 0.5(Lr or S or R)·WHITNEY STRESS BLOCKa = Asfy/(0.85f'cb), Mn = Asfy(d − a/2)·SEISMIC BASE SHEARV = CsW, Cs = SDS/(R/Ie)·EFFECTIVE STRESSσ' = σ − u·MOHR–COULOMBτf = c' + σ' tan φ'·BEARING CAPACITYqu = c'Nc + qNq + 0.5γBNγ·RANKINE EARTH PRESSUREKa = tan2(45° − φ'/2), Kp = tan2(45° + φ'/2)·PRIMARY CONSOLIDATIONSc = (CcH/(1 + e0))log10((σ'0 + Δσ')/σ'0)·TERZAGHI CONSOLIDATION∂u/∂t = cv∂2u/∂z2, Tv = cvt/Hdr2·DARCY’S LAWv = ki, Q = kiA·FLOW NET SEEPAGEq = kHNf/Nd·PHASE RELATIONSSe = wGs, e = n/(1 − n)·INFINITE SLOPEFS = tan φ'/tan β (c' = 0, dry)·BOUSSINESQ STRESSΔσz = 3Pz3/(2πR5), R2 = r2 + z2·MANNING’S EQUATIONV = (1/n)Rh2/3S1/2 (SI)·

The science on the shirt

What you’re wearing

Every object on the shirts, and the science behind it.

The Voussoir Arch

LOAD PATH

The Voussoir Arch

stands down to t = 0.1075 R

A ring of wedge-shaped stones stands as long as a line of thrust fits inside it; Jacques Heyman made that the modern safety check. A semicircular arch needs a ring only 0.1075 of its radius deep, the thrust grazing the intrados 54.5° from the crown. This one is nearly twice that; its keystone is simply the last stone set.

Gaudí’s Hanging Model

LOAD PATH

Gaudí’s Hanging Model

Colònia Güell, scale 1:10

Gaudí designed the Colònia Güell church upside down, refining a one-tenth-scale model of strings and sachets of lead shot for about ten years from 1898. A string can only pull, so each settles into the shape that carries its loads in tension; inverted, every member is in pure compression. Only the crypt was built.

Euler Buckling and Effective Length

LOAD PATH

Euler Buckling and Effective Length

K = 2, 1, 0.7, 0.5

Euler found in 1744 the load at which a slender column bows sideways. A flagpole buckles as a quarter wave at a quarter of the pinned-end load; clamped ends take four times it. Fixed and pinned, tan kL = kL gives K = 0.699. Codes raise the clamped values to 0.65 and 0.80, since no connection is perfectly rigid.

Parabola, Not Catenary

LOAD PATH

Parabola, Not Catenary

hangers grow as x²

A free chain hangs as a catenary, its weight spread along its length. Hang a level deck from it and the load is spread along the span instead: the curve becomes a parabola, and the hangers grow as the square of their distance from the center. Every suspension cable is designed that way.

Warren and Pratt Trusses

LOAD PATH

Warren and Pratt Trusses

Pratt diagonals: all tension

The Pratts patented their truss in 1844, Warren and Monzani theirs in 1848. The method of joints solves either, two equations at every joint. Loaded at its inner joints, the Pratt puts every diagonal in tension, 3.54, 2.12 and 0.71 times the joint load, and its center post and end bottom panels carry nothing: zero-force members.

Brooklyn Bridge Cable Spinning

MAIN SPAN

Brooklyn Bridge Cable Spinning

19 strands of parallel wire

Brooklyn’s four main cables, each 15¾ inches across, were spun in the air in 1877 and 1878. A wheel on an endless rope carried a loop of wire across on every trip, each wire set to the sag of a guide wire. They were bundled into 19 strands, one, six and twelve, then squeezed round and wrapped.

Cable-Stayed: Fan and Harp

MAIN SPAN

Cable-Stayed: Fan and Harp

harp: 8.6 % more stay steel

A cable-stayed deck hangs straight from its pylon, each stay carrying its share with a tension of ws/sin θ, so the flatter the stay, the harder it works. A fan runs every stay to the pylon head and keeps them steep. A harp keeps them parallel, which looks calm, but here needs 8.6% more stay steel.

Bridge Scour

MAIN SPAN

Bridge Scour

up to 2.4 pier widths deep

When a river meets a pier it plunges down the upstream face and rolls into a horseshoe vortex that lifts sand faster than the flow returns it. The Federal Highway Administration’s HEC-18 equation predicts the hole: 1.93 pier widths for a round pier in water three widths deep at a Froude number of 0.3, capped at 2.4.

Tacoma Narrows, 1940

MAIN SPAN

Tacoma Narrows, 1940

one node at midspan, 0.2 Hz

Tacoma Narrows opened on 1 July 1940: a 2,800-foot span, a deck only 39 feet wide on plate girders 8 feet deep. On 7 November, in a wind of about 42 mph, it twisted in its first antisymmetric torsional mode until the span tore loose. Not resonance: flutter, energy drawn from a steady wind.

The Forth Bridge Cantilever

MAIN SPAN

The Forth Bridge Cantilever

arms pull, sticks push

Baker explained the Forth Bridge with a photograph in 1887. Two men sit with arms out, gripping sticks braced against their chairs: arms in tension, sticks in compression, chairs as piers. Kaichi Watanabe, one of the engineers, sits between them as the suspended span, and piles of bricks hold down the outer arms.

The Cylinder Break

28 DAYS

The Cylinder Break

f ′c = 4P/πd² at 28 days

Standard cylinders, 150 by 300 mm or 100 by 200, are cast from the truck, cured and broken at 28 days; at 30 MPa a 150 mm cylinder fails at 530 kN. Platen friction confines the ends, so a good break is two cones. A diagonal shear or a split through a cap tells the technician something went wrong.

The Pantheon Dome

28 DAYS

The Pantheon Dome

43.3 m span, 5 × 28 coffers

Hadrian’s Pantheon, finished around AD 125, would hold a sphere 43.3 m across. Five rings of 28 coffers lighten the shell, and the aggregate grades from heavy stone to light pumice near the top. Under its own weight a hemisphere’s hoops go into tension beyond 51.8° from the crown, and the lower dome is cracked in just that zone.

The Slump Test

28 DAYS

The Slump Test

300 mm cone, 75 mm slump

A steel cone 300 mm tall, 200 mm across the base and 100 across the top, filled in three layers rodded 25 times each and lifted up. The drop is the slump, 75 mm here. A true slump keeps its form; a shear slump slides and a collapse spreads, and each says something different about the mix.

Confinement and the Seismic Hook

28 DAYS

Confinement and the Seismic Hook

135° hooks into the core

In an earthquake a column must hold its strength while bending far past yield. Closed hoops confine the core and stop the bars buckling once the cover spalls, but only if they stay shut: a 90° hook opens, while a 135° hook bent into the core with a tail of at least six bar diameters or 75 mm holds.

Post-Tensioning and Load Balancing

28 DAYS

Post-Tensioning and Load Balancing

upward load w = 8Pe/L²

Freyssinet’s answer to concrete’s weakness in tension, patented in 1928, was to squeeze it first. Drape the tendon in a parabola and, pulled tight, it pushes up with an even load, 8Pe/L². T. Y. Lin’s 1963 method cancels the self-weight with it: a 20 m beam with a 2,000 kN tendon draped 300 mm gets 12 kN per meter.

Mohr–Coulomb and the Triaxial Test

REFUSAL

Mohr–Coulomb and the Triaxial Test

fails on a plane at 45° + φ′/2

In the triaxial test a sealed soil cylinder, twice as tall as wide, is squeezed by water in a clear cell and loaded by a ram. A sand with a 30° friction angle fails at three times the cell pressure, on a plane at 45° plus half that angle: 60°. Bishop and Henkel’s 1957 book made it standard.

The Leaning Tower of Pisa

REFUSAL

The Leaning Tower of Pisa

eased back ½° in 1999–2001

Work stopped in 1178 with three stories done, and the pause probably saved the tower, letting the clay consolidate. Builders resuming in 1272 made the upper stories taller on the low side, hence the curve. Jamiolkowski’s commission, with Burland on the soil, eased it back about half a degree by 2001, leaving a lean of about 4°.

The Pressure Bulb

REFUSAL

The Pressure Bulb

0.1q reaches 2B deep

Boussinesq solved the stress under a point load on an elastic half-space in 1885. Summed under a square footing of width B, the stress falls to a half, a fifth and a tenth of the footing pressure at depths of 0.73B, 1.40B and 2.09B. That last depth is the borehole rule: investigate about two widths down.

The Liquid Limit

REFUSAL

The Liquid Limit

13 mm closes at 25 blows

Atterberg defined the limits of a clay in 1911; Casagrande made the liquid limit a machine. A cam lifts the brass cup 10 mm and drops it twice a second; the liquid limit is the water content at which 25 blows close the groove along 13 mm. By the one-point method, 42% water at 30 blows means 42.9%.

Seepage into a Cofferdam

REFUSAL

Seepage into a Cofferdam

4 flow channels, 10 drops

Groundwater obeys Laplace’s equation, so seepage under a sheet-pile wall can be drawn as a flow net of curvilinear squares, as Forchheimer did in 1911. Leakage is permeability times head times channels over drops. Here: four channels, ten drops a side. The exit gradient beside the pile is 0.43; near 1 the floor boils.

The Morning-Glory Spillway

FREEBOARD

The Morning-Glory Spillway

radial inflow, no vortex

A morning-glory spillway drains a full reservoir through a funnel in the lake: a circular crest, a bell-mouth, a vertical shaft and a tunnel. It suits narrow valleys and works as a weir bent into a circle. The best known is the Glory Hole at Monticello Dam in California, 72 feet across, completed in 1957.

The Egg-Shaped Sewer

FREEBOARD

The Egg-Shaped Sewer

height 1½ × width

A sewer must carry storms yet keep a dry-weather trickle moving fast enough to carry its solids. The Victorian egg stands on its narrow end, crown radius half the width, invert a quarter. At 2% of full flow, Manning’s equation puts the water 0.154 of the width deep, moving 10.5% faster than in a round pipe of equal area.

The Parshall Flume

FREEBOARD

The Parshall Flume

one depth reading gives Q

Ralph Parshall’s 1920s flume measures open-channel flow from one depth. The throat floor drops steeply, so the flow passes critical depth and the upstream depth depends on the flow alone. A one-foot throat passes four cubic feet per second at a depth of one foot, 11.5 at two, and silt that would clog a weir.

The Hydraulic Jump

FREEBOARD

The Hydraulic Jump

Fr 5: the depth jumps 6.6×

When fast, shallow water meets slow, deep water it jumps. Bélanger’s momentum balance makes the depth ratio depend only on the upstream Froude number: at 5 the water rises 6.59 times, through a churning roller, and loses 49% of its energy. Stilling basins hold a jump in place so that energy is spent on concrete, not on the riverbed.

The Miter Gate

FREEBOARD

The Miter Gate

the V always points upstream

Two leaves swing from the lock walls and meet in a shallow V pointing upstream, so the higher water pushes them together and the gate seals tighter the more it holds back. Each leaf is a strut carrying a thrust of pW/4 sin θ into the quoin. A rise of one in three, 18° off square, is the traditional compromise.
