Mechanical Engineering · Subject 18

Mechanical Engineering

Gear trains, linkages and Mohr’s circle, printed on button-ups, ties and socks.

This week in Mechanical Engineering,

Beams of many sizes make a tougher metamaterial, rubber tidal-turbine blades bend to shed load, cable-and-rod robots team up like trunks, and light-heated muscles paddle a printed frog.

Get it by email

Download MP3

Behind this page is an engineering drawing of a cabinet of mechanisms, all driven by one crank; scrolling turns it. Every machine is solved exactly from its link lengths, gear teeth and ratios. Parallel motion: a four-bar of links 1, 3.5, 3 and 4 (Grashof, so the crank turns fully) whose rocker swings 39.96 degrees and drives Watt’s linkage, straight to 1.35 mm over a 600 mm stroke; Jansen’s leg, its foot flat for 132 degrees of each turn; a cycloidal cam whose pressure angle never passes 17.8 degrees; a four-slot Geneva wheel that turns 90 degrees and rests for 270. Hunting tooth: an 18 and 29 tooth involute pair on its line of action, contact ratio 1.588; a planetary set 18, 27, 72 at 5 to 1; a 6205 bearing’s nine balls and cage. Infinite life: a rotating-beam specimen, one stress reversal a turn, its Mohr circle and the S-N curve, endurance limit 300 MPa at a million cycles. Top dead center: a steam engine drawing its indicator card, cut-off at a quarter stroke, mean effective pressure 3.21 bar, and a Wankel rotor at a third of shaft speed. No slip: a journal bearing at eccentricity ratio 0.6, its shaft 46.3 degrees off the load line. The page is one hunting period of the 18 to 29 pair: 29 turns and 522 tooth meshes, after which the marked teeth meet again.

Welcome in

For anyone who has rebuilt a gearbox

You know the smell of cutting fluid, the chatter of a tool set too far out of its holder, and the click of the torque wrench on the last head bolt. You know the moment a tensile bar starts to neck, the load falling while the crosshead keeps moving. You remember the first mechanism you built that moved the way the sums said it would: a four-bar on a pin board, or a cam you filed until the follower ran smoothly. You were an engineer from then on.

Start with everything

WORKING PARTS, Bone
WORKING PARTSRegular price $65 Sale price $58.50Shop now

Colorway
Bone

Whole-field medallions · repeats every 18 in

Short-sleeve button-up · XS–4XL

WORKING PARTS

The whole field, on one shirt.

Mechanical Engineering brought together in one design, printed edge to edge: 25 medallions from the field’s designs, with the equations from across the subject. Related images are spread across the pattern so no two neighbors repeat.

  • Print scaleThe pattern repeats every 18 inches, with seamless edges.
  • StylesPhotoreal on bone, engraving or blueprint.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

STRESS LINES, Machine green
STRESS LINESRegular price $65 Sale price $58.50Shop now

Colorway

Contour map · repeats every 18 in

Short-sleeve button-up · XS–4XL

STRESS LINES

A topographic portrait of the field.

Recognizable forms from Mechanical Engineering rise as contour landscapes. Lines follow the outlines and continue across the ground between them, with names fitted along the contours.

  • Print scaleThe pattern repeats every 18 inches, with seamless edges.
  • The paletteTwo colorways, shown at the same print scale.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Socks mix and match across every field: three pairs for $69, and two ship free in the U.S.

Crew socks · One size

Crew socks

A field of your own, from cuff to toe.

  • The pattern
  • The previewA studio mockup; photos of the finished pair are on the way.
Shop now · Regular price $26 Sale price $23.40

Leave your email and we’ll write the day this pair is ready.

Necktie · 3.5 in wide

Subject ties

A formal introduction to your field.

  • The color
  • The previewStudio render of the tie. Zoom shows the print up close.
Shop now · Regular price $36 Sale price $32.40

Leave your email and we’ll write the day this tie is ready.

More designs to explore

Short-sleeve button-up · XS–4XL

PARALLEL MOTION

A shaft turns at constant speed; these make it draw a line, pause, lift and walk.

In 1784 James Watt needed a piston rod to move straight while the end of his beam swung in an arc, and he found that two rockers pivoted at opposite ends and joined by a short link would do it. He later wrote that he was prouder of this parallel motion than of any other mechanical invention he had made. The midpoint of the link traces a figure-eight whose waist is almost straight: with one-meter rockers and a half-meter link it strays at most 1.35 mm over a 600 mm stroke. In 1883 Franz Grashof gave the rule that sorts every four-bar chain: if the shortest link plus the longest is no more than the other two, the shortest can turn all the way around.

A cam is a displacement program cut into metal: the designer writes down where the follower must be at every angle, and the profile follows. Cycloidal rise starts and stops with zero acceleration, and the price of a quick lift is the pressure angle, which past about 30° makes the follower bind; on this cam it never passes 18°. The Geneva drive, the Maltese cross of watchmaking, pulled film through projectors a frame at a time: its crank turns 90° to index the wheel a quarter turn, and a locking disk holds the wheel for the other 270°. And around 1990 Theo Jansen evolved the proportions of a leg on a home computer: eight links, ten pins, one degree of freedom, and a foot that stays level for 132° of every turn.

  • Watt’s LinkageBrass bars on steel posts with the midpoint’s path light-painted: a tall figure-eight whose waist is a straight line.
  • Jansen’s LinkageA brass leg of eight links and ten pins, one small crank at the top, the foot’s light trace flat-bottomed beneath it.
  • Cam and FollowerA steel disk cam and in-line roller follower, the roller halfway up the rising flank, a spring holding it down.
  • The Geneva DriveBlued-steel Maltese cross and brass driver, the pin inside one of four radial slots, the locking disk cut away beside it.
  • The Four-Bar LinkageA brass crank-rocker, links 1, 3.5, 3 and 4: the crank traces a circle, the rocker an arc, a coupler point a cusped teardrop.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

HUNTING TOOTH

Gears and a bearing, counted tooth by tooth and ball by ball.

Where they can, gear designers choose tooth counts with no common factor, so that each tooth meets every tooth of its partner before it meets the same one again, and wear spreads evenly. That is a hunting tooth. The involute pair here is one: 18 and 29 teeth at a 20° pressure angle, cut to the curve Euler proposed in the 1750s, which won because it keeps the speed ratio constant whatever the center distance. Every contact lies on one line tangent to both base circles, and a contact ratio of 1.588 means two pairs share the load 59% of the time. A car’s final drive is another: 41 and 11 share no factor, so the classic 3.73 : 1 wears in evenly.

The differential lets the outer wheel turn faster than the inner in a corner, 1.162 times as fast on a 10 m turn with a 1.5 m track, while its carrier runs at their average. Elsewhere the counts decide what can be built at all. In a planetary set the ring must equal the sun plus two planets, 18 + 54 = 72, and three planets space evenly only because 18 + 72 divides by three; four would not. Musser’s strain-wave gear, patented in 1959, works by giving its flexspline two teeth fewer than its ring, 15 : 1 here. And Conrad’s 1903 way of filling a deep-groove bearing leaves room in a 6205 size for nine balls, and not ten.

  • Strain Wave GearingA sectioned strain-wave gear: an oval flexspline of 30 teeth meeting the 32-tooth ring at top and bottom only, on a ring of balls.
  • The Planetary Gear SetSun 18, three planets of 27 at 120°, ring 72: a triangular carrier, and every tooth the same size.
  • The Deep-Groove Ball BearingA deep-groove bearing mid-assembly: the inner ring pushed hard to one side, nine touching balls in the crescent, no room for a tenth.
  • Involute Gear TeethSpur gears of 18 and 29 teeth and a gold thread tangent to both base circles: the line of action, both contacts on it.
  • The DifferentialA cutaway open differential: a 41-tooth ring, an 11-tooth pinion, and four bevel gears meshing in a square inside the carrier.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

INFINITE LIFE

What steel does before it breaks, and the one stress below which it never will.

Railway axles broke in the 1840s at loads well below their strength, and August Wöhler spent the following decades finding out why: a stress repeated millions of times cracks steel that would carry it indefinitely if applied once. His S–N curve levels off near a million cycles at the endurance limit, about half the tensile strength, and below it a steel part has infinite life. Above it a crack grows a little with every cycle, and each pause leaves a beach mark around the origin. The tensile test is where the education starts. Mild steel yields with a jolt as a Lüders band sweeps the bar, then strain-hardens until, exactly where Considère’s 1885 condition says, the bar begins to neck.

Mohr published his circle in 1882, and the thin pressure vessel is its classic trap. Hoop stress is pr/t and axial pr/2t, so the circle drawn in the plane of the wall gives a peak shear of pr/4t; but the radial stress is nearly zero, and the big circle through it gives pr/2t, twice as much. Tresca in 1864 and von Mises in 1913 turned one tensile test into a rule for combined loads: a hexagonal prism and a cylinder in principal-stress space, never more than 15.5% apart. And Charpy’s pendulum of 1901 measures toughness by how high it fails to swing, a test that earned its place after the brittle fractures of the wartime Liberty ships.

  • Fatigue and the Endurance LimitA broken round bar, face on: nine beach marks curving around one origin, and a rough, bright final zone along the opposite edge.
  • The Stress–Strain Curve of Mild SteelFive flat steel bars, each stopped at a landmark: untested, crossed by a slanting Lüders band, evenly stretched, necked, broken on a slant.
  • Von Mises and TrescaA clear glass cylinder with an amber hexagonal prism inscribed, on brass axes, the shared axis equally inclined to all three.
  • The Charpy Impact TestA scale Charpy pendulum by long exposure: the light trail higher on the release side, the notch facing away from the striker.
  • Mohr’s CircleThree brass hoops on one rod, two small ones exactly equal inside a large one, blue enamel where every plane’s stress can lie.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

TOP DEAD CENTER

Heat into work, four ways, and the share the second law lets you keep.

Robert Stirling, a Scottish minister, patented his hot-air engine in 1816. A displacer shuttles a fixed charge of air between a hot space and a cold one while a power piston takes work from the pressure swing, and with a perfect regenerator the ideal cycle reaches the Carnot efficiency, one of the few that can. The desk engines that run on a cup of coffee make the limit tangible: at 85 °C in a 20 °C room no engine can beat 18.1%. Rudolf Diesel did away with the spark in the 1890s. Squeeze air twenty to one too fast for heat to escape and it goes from 293 K to 972 K, hot enough to light fuel, or the tinder in a fire piston.

With a 2 : 1 cut-off the ideal Diesel cycle returns less than an Otto cycle at the same ratio, 64.7% against 69.8% at twenty to one, but a diesel can run at ratios that would make a gasoline engine knock. Felix Wankel’s engine, first run in 1957, runs the Otto cycle in three chambers at once, its rotor turning at a third of the shaft’s speed through a 3 : 2 gear so that all three tips follow the housing. The first pressure–volume diagrams were drawn by engines themselves, on the indicator Watt’s assistant John Southern built in 1796. And boilers and reactor fuel rods are designed around Nukiyama’s 1934 discovery: past the critical heat flux, 1.26 MW/m² for water at one atmosphere, the surface blankets itself in vapor.

  • The Stirling EngineA low-temperature Stirling engine on a cup of coffee: a wide, flat displacer, a small piston, cranks 90° apart, a big spoked flywheel.
  • The Diesel CycleA glass fire piston at the moment of ignition: the brass plunger nearly home, one ember glowing at its tip.
  • The Indicator DiagramA brass steam-engine indicator and its penciled card: flat admission, falling expansion curve, the atmospheric line ruled below.
  • The Wankel EngineA face-on cutaway: triangular rotor in a two-lobed bore, all three apex seals on the wall, its gear meshing 3 : 2.
  • The Boiling CurveFilm boiling on a platinum wire: the wire glowing orange inside a smooth vapor sheath, big bubbles leaving at regular intervals.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

NO SLIP

Fluid sticks to every surface it touches, and wakes, drag, turbines and bearings follow.

A fluid touching a wall moves with the wall. It sounds like a footnote, and it is where boundary layers, skin friction and lubrication come from. Behind a cylinder it rolls the wake into vortices shed from alternate sides, at a frequency Strouhal measured in 1878: fD/U stays near 0.2 over a vast range of Reynolds numbers, so a 3 mm wire in a 10 m/s wind sings at 667 Hz. Von Kármán showed in 1911 that the staggered street is stable only with its rows 0.281 of the vortex spacing apart. Around a sphere the boundary layer decides the drag: near a Reynolds number of 3.5 × 10⁵ it turns turbulent, clings farther around the back, and the drag coefficient falls from about 0.47 to about 0.1.

Nikola Tesla’s bladeless turbine of 1913 runs on viscous drag alone: gas spirals inward between flat disks and drags them around, so the gaps must be comparable with the boundary layer, whose scale for air at 10,000 rpm is 0.12 mm. In 1883 Beauchamp Tower found an oiled railway bearing pushing the plug out of an oil hole, and Osborne Reynolds explained it in 1886: the turning shaft drags oil into the narrowing gap and floats on it, settling off to one side rather than straight under the load. And Lester Pelton’s split bucket of 1880 turns a jet almost straight back; running at half the jet’s speed, it leaves the water nearly at rest, for an ideal efficiency of 98.3%.

  • The Pelton WheelA bronze Pelton runner of twenty split buckets, one jet striking at the bottom, the water leaving sideways in two sheets.
  • The Tesla TurbineA cutaway Tesla rotor: a stack of flat disks with narrow gaps, six exhaust holes by the shaft, flow traces spiraling in from one nozzle.
  • The Journal BearingEnd-on through glass: a steel shaft in a glowing oil film, thickest at upper left, thinnest about 45° around from the bottom.
  • The Kármán Vortex StreetA soap-film street in interference colors: vortices alternating top and bottom behind a small dark disk, the rows spinning opposite ways.
  • The Drag CrisisTwo spheres in smoke: the plain one trailing a wake wider than itself, the one with a trip-wire ring a much narrower wake.
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

Short-sleeve button-up · XS–4XL

EQUATION STRIPE

From Hooke’s law to Taylor tool life, every line labeled.

Mechanical engineering is taught as a sequence of courses, and each one leaves behind a handful of equations that never quite go away. The Equation Stripe sets forty-five of them in rows, each introduced by its name in capitals, so FLEXURE FORMULA, GOODMAN CRITERION and DITTUS–BOELTER read at a glance. Together they make a working mechanical engineer’s toolkit: how parts are stressed, how they fatigue and crack, how they move and vibrate, how machine elements are sized, how heat and fluid are made to do work, and how machines are controlled and cut.

Ten meet the picture designs head on: HOOP STRESS and PRINCIPAL STRESSES for Mohr’s circle, VON MISES STRESS, BASQUIN’S LAW for the fatigue fracture, BEARING LIFE, GRÜBLER–KUTZBACH for Jansen’s leg, CARNOT EFFICIENCY and OTTO CYCLE for the engines, and REYNOLDS NUMBER and DRAG EQUATION for the drag crisis. The rest come from the first years of the degree and stay for the career: Euler buckling, the Paris law of crack growth, Lagrange’s equations, transmissibility, the capstan equation, the steady-flow energy equation, Navier–Stokes and the pump affinity laws.

  • Hooke’s Lawεx = [σx − ν(σy + σz)]/E
  • Flexure Formulaσx = −My/I
  • Torsion Formulaτ = Tρ/J, φ = TL/(GJ)
  • Shear Formulaτ = VQ/(It)
  • Principal Stressesσ1,2 = (σx + σy)/2 ± √(((σx − σy)/2)2 + τxy2)
  • Von Mises StressσvM = √(((σ1 − σ2)2 + (σ2 − σ3)2 + (σ3 − σ1)2)/2)
Shop now · Regular price $65 Sale price $58.50

Leave your email and we’ll write the day it’s ready.

HOOKE’S LAWεx = [σx − ν(σy + σz)]/E·FLEXURE FORMULAσx = −My/I·TORSION FORMULAτ = Tρ/J, φ = TL/(GJ)·SHEAR FORMULAτ = VQ/(It)·PRINCIPAL STRESSESσ1,2 = (σx + σy)/2 ± √(((σx − σy)/2)2 + τxy2)·VON MISES STRESSσvM = √(((σ1 − σ2)2 + (σ2 − σ3)2 + (σ3 − σ1)2)/2)·EULER BUCKLINGPcr = π2EI/(KL)2·HOOP STRESSσθ = pr/t, σz = pr/(2t)·STRESS CONCENTRATIONKt = σmax/σ = 1 + 2√(a/ρ)·HERTZ CONTACTa = (3FR/(4E*))1/3, p0 = 3F/(2πa2)·BASQUIN’S LAWσa = σ'f(2Nf)b·GOODMAN CRITERIONσa/Se + σm/Sut = 1/n·PALMGREN–MINER RULE∑ini/Ni = 1·PARIS LAWda/dN = C(ΔK)m·STRESS INTENSITYKI = Yσ√(πa)·LAGRANGE’S EQUATIONS(d/dt)(∂L/∂q̇i) − ∂L/∂qi = Qi·EULER’S EQUATIONSI1ω̇1 + (I3 − I2)ω2ω3 = M1·RELATIVE ACCELERATIONaP = aO + Ω̇×r + Ω×(Ω×r) + 2Ω×vrel + arel·DAMPED OSCILLATORmẍ + cẋ + kx = F(t)·NATURAL FREQUENCYωn = √(k/m), ζ = c/(2√(km)), ωd = ωn√(1 − ζ2)·TRANSMISSIBILITYTR = √((1 + (2ζr)2)/((1 − r2)2 + (2ζr)2)), r = ω/ωn·LOGARITHMIC DECREMENTδ = ln(xn/xn+1) = 2πζ/√(1 − ζ2)·HELICAL SPRING RATEk = Gd4/(8D3Na)·BOLT PRELOAD TORQUET = KFid, K ≈ 0.2·HOOKE’S LAWεx = [σx − ν(σy + σz)]/E·FLEXURE FORMULAσx = −My/I·TORSION FORMULAτ = Tρ/J, φ = TL/(GJ)·SHEAR FORMULAτ = VQ/(It)·PRINCIPAL STRESSESσ1,2 = (σx + σy)/2 ± √(((σx − σy)/2)2 + τxy2)·VON MISES STRESSσvM = √(((σ1 − σ2)2 + (σ2 − σ3)2 + (σ3 − σ1)2)/2)·EULER BUCKLINGPcr = π2EI/(KL)2·HOOP STRESSσθ = pr/t, σz = pr/(2t)·STRESS CONCENTRATIONKt = σmax/σ = 1 + 2√(a/ρ)·HERTZ CONTACTa = (3FR/(4E*))1/3, p0 = 3F/(2πa2)·BASQUIN’S LAWσa = σ'f(2Nf)b·GOODMAN CRITERIONσa/Se + σm/Sut = 1/n·PALMGREN–MINER RULE∑ini/Ni = 1·PARIS LAWda/dN = C(ΔK)m·STRESS INTENSITYKI = Yσ√(πa)·LAGRANGE’S EQUATIONS(d/dt)(∂L/∂q̇i) − ∂L/∂qi = Qi·EULER’S EQUATIONSI1ω̇1 + (I3 − I2)ω2ω3 = M1·RELATIVE ACCELERATIONaP = aO + Ω̇×r + Ω×(Ω×r) + 2Ω×vrel + arel·DAMPED OSCILLATORmẍ + cẋ + kx = F(t)·NATURAL FREQUENCYωn = √(k/m), ζ = c/(2√(km)), ωd = ωn√(1 − ζ2)·TRANSMISSIBILITYTR = √((1 + (2ζr)2)/((1 − r2)2 + (2ζr)2)), r = ω/ωn·LOGARITHMIC DECREMENTδ = ln(xn/xn+1) = 2πζ/√(1 − ζ2)·HELICAL SPRING RATEk = Gd4/(8D3Na)·BOLT PRELOAD TORQUET = KFid, K ≈ 0.2·

The science on the shirt

What you’re wearing

Every object on the shirts, and the science behind it.

Watt’s Linkage

PARALLEL MOTION

Watt’s Linkage

1.35 mm off true in 600 mm

In 1784 Watt needed a piston rod to run straight while his beam rocked. Two rockers and a short link did it; he was prouder of it than of any other invention. The link’s midpoint draws a figure-eight, straying 1.35 mm over a 600 mm stroke with one-meter rockers. Some cars still locate their rear axles this way.

Jansen’s Linkage

PARALLEL MOTION

Jansen’s Linkage

foot flat for 132° of a turn

Theo Jansen’s beach animals walk on wind. Each leg has eight links and ten pins, one degree of freedom by Grübler’s count. For 132° of each crank turn the foot stays within 0.5 of a straight line over a stride of 50, level under load, then lifts and swings back: one crank, no controller.

Cam and Follower

PARALLEL MOTION

Cam and Follower

pressure angle never over 18°

A cam is a displacement program cut into metal. This one rises 20 mm in 120°, dwells for 60°, returns in 120° and dwells again, all cycloidal, so the follower never jerks. On a 40 mm base circle with a 10 mm roller the pressure angle peaks at 17.8°, comfortably inside the usual 30° limit.

The Geneva Drive

PARALLEL MOTION

The Geneva Drive

turns 90°, rests for 270°

The Maltese cross of watchmaking. With four slots the pin enters and leaves each slot radially, so the wheel starts and stops at rest: a quarter turn, then a dwell for three-quarters of the crank’s turn. Peak wheel speed is 2.414 times the crank’s. The jolt of acceleration at entry limits how fast it can run.

The Four-Bar Linkage

PARALLEL MOTION

The Four-Bar Linkage

Grashof: 1 + 4 < 3.5 + 3

Grashof’s rule of 1883: if the shortest link plus the longest is no more than the other two, the shortest can turn fully around. Here 1 plus 4 is under 3.5 plus 3, so the crank turns and the rocker swings 39.96°. A coupler point on the moving centrode, momentarily at rest, draws a sharp cusp.

Strain Wave Gearing

HUNTING TOOTH

Strain Wave Gearing

two teeth fewer: 15 : 1

C. Walton Musser patented strain-wave gearing in 1959. An elliptical wave generator bends a thin toothed flexspline so it meshes with a rigid ring at two places only. With two teeth fewer, each turn of the ellipse walks it back two teeth: 15 : 1 for this 30-and-32 model, 100 : 1 for a typical 200-tooth unit, with no backlash.

The Planetary Gear Set

HUNTING TOOTH

The Planetary Gear Set

18 + 2 × 27 = 72, so 5 : 1

Robert Willis analyzed epicyclic trains in 1841 by watching them from the rotating carrier. With the 72-tooth ring held and the 18-tooth sun driving, the carrier turns once for every five turns of the sun. The ring equals the sun plus two planets, and 18 plus 72 divides by three, so three planets space evenly; four would not.

The Deep-Groove Ball Bearing

HUNTING TOOTH

The Deep-Groove Ball Bearing

9 balls: a tenth won’t fit

Deep grooves carry thrust as well as radial load, which means the balls cannot simply be pushed in. Robert Conrad’s 1903 answer: shove the inner ring to one side, drop the balls into the crescent, center the ring and fit a cage. In a 6205 size the crescent spans 194.2°, touching balls take 23.8° each, and nine fit.

Involute Gear Teeth

HUNTING TOOTH

Involute Gear Teeth

20° pressure angle, 18 : 29

Unwind a taut string from a circle and its end draws an involute. Euler proposed it for gear teeth in the 1750s, and it won: every contact lies on one line tangent to both base circles, so the ratio holds whatever the center distance. Eighteen teeth is the fewest a 20° pinion can have without undercut: 2/sin²20° is 17.1.

The Differential

HUNTING TOOTH

The Differential

41 : 11, a hunting ratio

Pecqueur’s bevel-gear differential of 1827 lets the outer wheel outrun the inner in a corner, the carrier turning at their average. Torque splits equally, so one wheel on ice leaves the other with almost nothing. The ring and pinion hunt: 41 and 11 share no factor, so each pinion tooth meets all 41 ring teeth in turn.

Fatigue and the Endurance Limit

INFINITE LIFE

Fatigue and the Endurance Limit

infinite life below ½ UTS

Wöhler’s railway axles showed that steel breaks under loads far below its strength if they repeat. His S–N curve levels off near a million cycles at about half the tensile strength: below it, infinite life. Above it a crack creeps from a surface flaw, each pause leaving a beach mark, until the last ligament fails at once, rough and bright.

The Stress–Strain Curve of Mild Steel

INFINITE LIFE

The Stress–Strain Curve of Mild Steel

necks where dσ/dε = σ

Everyone’s first lab report has this curve. Carbon and nitrogen atoms pin mild steel’s dislocations, so it yields with a jolt, an upper yield point dropping to a lower one while a Lüders band sweeps the bar. Then it strain-hardens until the true strain equals the hardening exponent, Considère’s 1885 condition, and the neck begins.

Von Mises and Tresca

INFINITE LIFE

Von Mises and Tresca

never more than 15.5 % apart

Tresca proposed in 1864 that metal yields when its largest shear stress reaches half the yield stress; von Mises in 1913, when its distortion energy matches the tensile test’s. In principal-stress space one is a hexagonal prism, the other a cylinder, both along the axis 54.7° from each stress axis: pressure alone never yields a metal.

The Charpy Impact Test

INFINITE LIFE

The Charpy Impact Test

notch away from the striker

Charpy’s 1901 pendulum breaks a notched bar and swings on; the height it fails to regain is the energy absorbed. A 300 J machine released from 150° strikes at 5.41 m/s. Tough steel taking 120 J lets it swing on to 96.9°; below its transition, the same steel takes 10 J and the hammer sails on to 143.5°.

Mohr’s Circle

INFINITE LIFE

Mohr’s Circle

τmax = pr/2t, not pr/4t

The thin pressure vessel is where Mohr’s 1882 circle catches people out. At 2 MPa, 200 mm radius and a 10 mm wall, hoop stress is 40 MPa and axial 20. The circle in the wall’s plane gives 10 MPa of shear; the big circle through the near-zero radial stress gives 20, on planes at 45° through the wall.

The Stirling Engine

TOP DEAD CENTER

The Stirling Engine

Carnot at 85 °C: 18.1 %

Stirling’s 1816 engine shuttles one charge of air between hot and cold; with a perfect regenerator its ideal cycle matches Carnot. On coffee at 85 °C in a 20 °C room no engine can beat 18.1%; on a palm at 34 °C, 4.6%, and a good one still runs. Hence the big displacer and small piston.

The Diesel Cycle

TOP DEAD CENTER

The Diesel Cycle

20 : 1 takes air to 700 °C

Diesel’s engine and the fire piston, long used in South-East Asia, share one idea: compress air twenty to one too fast for heat to escape and it reaches 972 K, 699 °C, hot enough to light tinder or fuel with no spark. With a 2 : 1 cut-off the ideal Diesel cycle then returns 64.7%, the Otto 69.8%.

The Indicator Diagram

TOP DEAD CENTER

The Indicator Diagram

cut-off at ¼ stroke

In 1796 Watt’s assistant John Southern built the first indicator, and the firm kept it secret for years. A spring-loaded piston moves a pencil with the pressure while the card moves with the engine: the loop’s area is the work of one stroke. It predates Clapeyron’s diagram by nearly forty years. This card’s mean effective pressure: 3.21 bar.

The Wankel Engine

TOP DEAD CENTER

The Wankel Engine

rotor turns at ⅓ shaft speed

Felix Wankel’s engine, first run in 1957, swaps pistons for a triangular rotor turning at a third of shaft speed, so its tips trace the two-lobed epitrochoid exactly. For a 105 mm generating radius, 15 mm eccentricity and 80 mm width, each face displaces 654.7 cc. Bare flanks would give 18.3 : 1 compression; a recess brings it near 9.4.

The Boiling Curve

TOP DEAD CENTER

The Boiling Curve

burnout at 1.26 MW/m²

In 1934 Nukiyama heated wires in boiling water until, at a certain heat flux, a nichrome one burned out. Platinum survived: vapor blanketed it and its temperature jumped by hundreds of degrees. Zuber’s theory, with Lienhard’s 0.149, puts that critical flux at 1.26 MW/m² for water at one atmosphere, reached only about 21 K above saturation.

The Pelton Wheel

NO SLIP

The Pelton Wheel

buckets at half the jet speed

Lester Pelton’s split bucket, patented in 1880 in the California gold country, turns a jet almost straight back. At half the jet’s speed the water leaves nearly at rest: with a 165° turn the ideal efficiency peaks at 98.3%. Under 500 m of head the jet runs at 97 m/s. The splitter ridge cancels the sideways forces.

The Tesla Turbine

NO SLIP

The Tesla Turbine

bladeless, patented 1913

Nikola Tesla patented his bladeless turbine in 1913. Gas enters at the rim of flat disks and spirals inward; sticking to them, it drags them around. For air at 10,000 rpm the boundary-layer scale is 0.12 mm, hence the tight gaps. Tests have always come in below bladed turbines, but its pump form handles abrasive and delicate fluids.

The Journal Bearing

NO SLIP

The Journal Bearing

shaft moves 46° off the load

In 1883 Beauchamp Tower found oil pushing the plug out of a railway bearing: it was making its own pressure. Reynolds explained it in 1886. The shaft floats on oil it drags in, and settles not under the load but to one side: 46.3° off at an eccentricity ratio of 0.6, by short-bearing theory.

The Kármán Vortex Street

NO SLIP

The Kármán Vortex Street

St = fD/U ≈ 0.2

Flow past a cylinder sheds vortices from alternate sides, and fD/U stays near 0.2, so a 3 mm wire in a 10 m/s wind sings at 667 Hz. Von Kármán showed in 1911 that the staggered rows are stable only 0.281 of a vortex spacing apart. The same shedding is why tall chimneys wear helical strakes.

The Drag Crisis

NO SLIP

The Drag Crisis

separation 82° → 120°

Near a Reynolds number of 3.5 × 10⁵ a smooth sphere’s drag coefficient falls from about 0.47 to about 0.1. Eiffel measured it in 1912 and Prandtl explained it in 1914: a turbulent boundary layer clings on longer, separating near 120° instead of 82° in Achenbach’s measurements. Dimples do for a golf ball what Prandtl’s trip wire did.
